LMX2492EVM ,Microprocessor Development Kit - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

66 points

Part No

LMX2492EVM
Manufacturer

TI
ChipWorker Part#

CW7842685
Category

Microprocessor Development Kit
Description

TEXAS INSTRUMENTS LMX2492EVM Evaluation Board, Ultralow Noise Frequency Synthesizer, Integrated VCO, FSK/PSK, SMA
Documentation

Datasheet
Ships from

Moscow
Наличие

27 pcs In Stock
Estimated Price

$ 358.8

Buy LMX2492EVM

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

LMX2492EVM Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

LMX2492EVM Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	LMX2492EVM
Manufacturer	TI
ChipWorker Part#	CW7842685
Category	Microprocessor Development Kit
Documentation	Datasheet
Frequency	5 GHz, 10 GHz
	expand all
Product Lifecycle Status	Unknown
Packaging	Bulk
RoHS	Non-Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The LMX2492EVM from Texas Instruments is an LMX2492 evaluation module. It supports evaluation of the LMX2492 and LMX2492-Q1 which is an ultra low noise 14GHz wideband RF PLL with ramp/chirp generation, consisting of a delta sigma fractional N PLL, phase detector, programmable 5V charge pump and high frequency divider for the VCO. The LMX2492 supports a broad and flexible class of ramping capabilities. It is able to generate FSK and PSK modulation, triangular, saw tooth and customizable ramp pattern. In addition, it supports fine PLL resolution and fast ramp with up to 200MHz phase detector rate. The LMX2492 allows any of its registers to be read back through a 3-wire interface and includes digital lock detect, programmable charge pump current and output power. The LMX2492 can operate with a single 3.3V supply. Moreover, the 5V charge pump eliminates the need of external op-amp, leading to improved phase noise performance.
Normalized PLL noise in fractional mode is -227dBc/Hz
500MHz to 14GHz wideband PLL
3.15V to 5.5V charge pump PLL voltage
Integrated FMCW ramp/chirp generation
FSK/PSK modulation
Excellent ramp linearity
200MHz maximum phase detector frequency
Integrated LDO for digital supply
Frequency/phase modulation terminal
