LPC2101FBD48
Manufacturer

NXP
ChipWorker Part#

CW135162945
Package

LQFP
Description

Single-chip 16Bit/32Bit microcontrollers; 8KB/16KB/32KB flash with ISP/IAP, fast ports and 10Bit ADC
Documentation

Datasheet

LPC2101FBD48 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

LPC2101FBD48 Specifications

Attribute	Attribute Value

Part Number	LPC2101FBD48
Manufacturer	NXP
ChipWorker Part#	CW135162945
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	48 Pin
Case/Package	LQFP
Supply Voltage (DC)	1.65V (min)
Number of Outputs	32 Output
Clock Speed	70.0 MHz
RAM Memory Size	2 KB
FLASH Memory Size	8192 B
Memory Size	8000 B
Supply Voltage (Max)	1.95 V
Supply Voltage (Min)	1.65 V
	expand all
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

General description
The LPC2101/02/03 microcontrollers are based on a 16-bit/32-bit ARM7TDMI-S CPU with real-time emulation that combines the microcontroller with 8 kB, 16 kB or 32 kB of embedded high-speed flash memory. A 128-bit wide memory interface and a unique accelerator architecture enable 32-bit code execution at the maximum clock rate. For critical performance in interrupt service routines and DSP algorithms, this increases performance up to 30 % over Thumb mode. For critical code size applications, the alternative 16-bit Thumb mode reduces code by more than 30 % with minimal performance penalty.
