LTC3832EGN - Linear Technology

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

LTC3832EGN
Manufacturer

Linear Technology
ChipWorker Part#

CW133232000
Category

Voltage Regulator
Package

SSOP-16
Description

DC-DC Cntrlr Single-OUT Step Down 500kHz 16Pin SSOP N
Documentation

Datasheet

LTC3832EGN Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

LTC3832EGN Specifications

Attribute	Attribute Value

Part Number	LTC3832EGN
Manufacturer	Linear Technology
ChipWorker Part#	CW133232000
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SSOP-16
Supply Voltage (DC)	5.00 V
Number of Outputs	1 Output
Output Voltage	2.5 V
Output Current	20 A
Switching Frequency	300 kHz
Input Voltage (Max)	8 V
Input Voltage (Min)	3 V
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	3V ~ 8V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
RoHS	Non-Compliant
Lead-Free Status	Contains Lead

Product Description

Looking for a step up or step down in voltage within a DC circuit, look no further: this synchronous step down LTC3832EGN DC voltage controller from Linear Technology will adjust the voltage properly. Its output produces a current of 20 A. With an output that has a voltage of 0.6 to 7.28|2.5 V, this is power management at its best. This DC voltage controller has single output. This DC voltage controller has an input voltage of 3 to 8 V. It has a switching frequency of 100 to 500 kHz. This DC voltage controller has a minimum operating temperature of -40 °C and a maximum of 85 °C.
