MAX3221EEAE+
Manufacturer

Maxim Integrated
ChipWorker Part#

CW2371096
Category

Interface IC, Interface Controller
Package

SSOP-16
Description

MAXIM INTEGRATED PRODUCTS MAX3221EEAE+ RS232 Transmitter/Receiver With shutdown mode. (SSOP, IND TEMP), SSOP-16
Documentation

Datasheet

MAX3221EEAE+ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MAX3221EEAE+ Specifications

Attribute	Attribute Value

Part Number	MAX3221EEAE+
Manufacturer	Maxim Integrated
ChipWorker Part#	CW2371096
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SSOP-16
Supply Voltage (DC)	3.00V (min)
Current Rating	300 mA
Supply Current	1 mA
Number of Channels	1 Channel
Number of Positions	16 Position
Data Rate	235 kbps
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	6.33 mm
Size-Width	5.38 mm
Size-Height	1.78 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15

Product Description

The MAX3221EEAE+ is a RS-232 Transceiver for handheld equipment. The MAX3221E is 3V-powered EIA/TIA-232 and V.28/V.24 communications interfaces with automatic shutdown/wakeup features, high data rate capabilities and enhanced electrostatic discharge (ESD) protection. All transmitter outputs and receiver inputs are protected to ±15kV using IEC 1000-4-2 air-gap discharge, to ±8kV using IEC 1000-4-2 contact discharge and to ±15kV using the human body model. The MAX3221E achieve a 1µA supply current with Maxim"s revolutionary AutoShutdown™ feature. They save power without changes to the existing BIOS or operating system by entering low-power shutdown mode when the RS-232 cable is disconnected or when the transmitters of the connected peripherals are off. The transceiver have a proprietary low-dropout transmitter output stage, delivering true RS-232 performance from a +3.0 to +5.5V supply with a dual charge pump.
