SN74LS245N - TI
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoSN74LS245N
-
ManufacturerTI
-
ChipWorker Part#CW291704
-
CategoryLogic Controller, Logic IC
-
PackagePDIP-20
-
DescriptionTEXAS INSTRUMENTS SN74LS245N Transceiver, 74LS245, 4.75V to 5.25V, DIP-20
-
DocumentationDatasheet
