MAX485EPA+ - Maxim Integrated

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MAX485EPA+
Manufacturer

Maxim Integrated
ChipWorker Part#

CW1698034
Category

Interface IC, Interface Controller
Package

DIP-8
Description

Transceiver RS422, RS485, 4.75V-5.25V supply, 1 Driver, DIP-8
Documentation

Datasheet

MAX485EPA+ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MAX485EPA+ Specifications

Attribute	Attribute Value

Part Number	MAX485EPA+
Manufacturer	Maxim Integrated
ChipWorker Part#	CW1698034
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Voltage (DC)	4.75V (min)
Number of Positions	8 Position
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	4.75V ~ 5.25V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	4.75 V
	expand all
Size-Length	9.91 mm
Size-Width	7.87 mm
Size-Height	2.03 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

The MAX485EPA+ is a low power RS485/RS422 transceiver in 8 pin DIP package. It contains one driver and one receiver. The slew rate is not limited allowing it to transmit up to 2.5Mbps. The driver is short circuit current limited and is protected against excessive power dissipation by thermal shutdown circuitry that places the driver outputs into a high impedance state. It features fail-safe circuitry which has a logic high receiver output when the receiver input is open.
Supply voltage range from 4.75V to 5.25V
Operating temperature range from -40°C to 85°C
Designed for half duplex communication
Features receiver/driver enable function
Quiescent current is 300µA
Allows up to 32 transceivers on the bus
