MAX705 - Maxim Integrated

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MAX705
Manufacturer

Maxim Integrated
ChipWorker Part#

CW481524021
Category

Voltage Reference
RoHS

Lead free / RoHS Compliant
Description

Low-Cost, µP Supervisory CircuitsLow-Cost Reset + Watchdog ICs
Documentation

Datasheet

MAX705 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MAX705 Specifications

Attribute	Attribute Value

Part Number	MAX705
Manufacturer	Maxim Integrated
ChipWorker Part#	CW481524021
Category	Voltage Reference
Documentation	Datasheet
Case/Package	µMAX-8
	expand all
Product Lifecycle Status	Unknown
RoHS	RoHS Compliant

Product Description

Description
The MAX705–MAX708/MAX813L microprocessor (µP) supervisory circuits reduce the complexity and number of components required to monitor power-supply and battery functions in µP systems. These devices significantly improve system reliability and accuracy compared to separate ICs or discrete components.
The MAX705/MAX706/MAX813L provide four functions:
1. A reset output during power-up, power-down, and brownout conditions.
2. An independent watchdog output that goes low if the watchdog input has not been toggled within 1.6 seconds.
3. A 1.25V threshold detector for power-fail warning, low-battery detection, or for monitoring a power supply other than +5V.
4. An active-low manual-reset input.
The MAX707/MAX708 are the same as the MAX705/MAX706, except an active-high reset is substituted for the watchdog timer. The MAX813L is the same as the MAX705, except RESET is provided instead of active-low RESET.
Two supply-voltage monitor levels are available: The MAX705/MAX707/MAX813L generate a reset pulse when the supply voltage drops below 4.65V, while the MAX706/MAX708 generate a reset pulse below 4.40V. All four parts are available in 8-pin DIP, SO and µMAX® packages.
