MBRM120LT1G ,Schottky Diode - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

147 points

Part No

MBRM120LT1G
Manufacturer

ON Semiconductor
ChipWorker Part#

CW164830
Category

Schottky Diode
Package

DO-216AA
Description

ON Semi MBRM120LT1G, SMT Schottky Diode, 20V 1A, 2Pin Power Mite
