MC33151PG - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MC33151PG
Manufacturer

ON Semiconductor
ChipWorker Part#

CW3622837
Category

FET Driver
Package

PDIP-8
Description

MC Series 1.5A 20V 100KΩ High Speed Dual MOSFET Driver - PDIP-8
Documentation

Datasheet

MC33151PG Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MC33151PG Specifications

Attribute	Attribute Value

Part Number	MC33151PG
Manufacturer	ON Semiconductor
ChipWorker Part#	CW3622837
Category	FET Driver
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	PDIP-8
Supply Voltage (DC)	18.0V (max)
Rise/Fall Time	31ns, 32ns
Halogen Free Status	Halogen Free
Number of Outputs	2 Output
Output Voltage	11.2 V
Output Current	1.50 A
Number of Positions	8 Position
Power Dissipation	1 W
Rise Time	31 ns
Output Current (Max)	1.5 A
Fall Time	32 ns
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1000 mW
Supply Voltage	6.5V ~ 18V
Supply Voltage (Max)	18 V
Supply Voltage (Min)	6.5 V
	expand all
Size-Length	10.02 mm
Size-Width	7.11 mm
Size-Height	5.33 mm
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The MC33151PG is a dual inverting high speed MOSFET Driver specifically designed for applications that require low current digital circuitry to drive large capacitive loads with high slew rates. This device features low input current making them CMOS and LSTTL logic compatible, input hysteresis for fast output switching that is independent of input transition time and two high current totem pole outputs ideally suited for driving power MOSFET. Also included is an under-voltage lockout with hysteresis to prevent erratic system operation at low supply voltages.
