MEE1S2405SC - muRata
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoMEE1S2405SC
-
ManufacturermuRata
-
ChipWorker Part#CW36525518
-
CategoryDC to DC Converter, DC/DC Converter
-
PackageSIP-4
-
DescriptionMURATA POWER SOLUTIONS MEE1S2405SC Isolated Board Mount DC-DC Converter, SIP, Fixed, Through Hole, 1W, 5V, 200mA
-
DocumentationDatasheet
Payment Methods and Delivery
{{ estimate }}
MEE1S2405SC Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
- |
{{outStock}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
- | ${{UpToFourDecimals(priceCalc,skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
{{ apiText }}{{ apiTime }}(UTC+8)
MEE1S2405SC Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | MEE1S2405SC |
| Manufacturer | muRata |
| ChipWorker Part# | CW36525518 |
| Category | DC to DC Converter, DC/DC Converter |
| Documentation | Datasheet |
| Mounting Style | Through Hole |
| Number of Pins | 4 Pin |
| Case/Package | SIP-4 |
| Supply Voltage (DC) | 24.0 V |
| Power Rating | 1 W |
| Number of Outputs | 1 Output |
| Input Voltage (DC) | 24.0 V |
| Output Voltage | 5 V |
| Output Current | 200 mA |
| Output Power | 1 W |
| Isolation Voltage | 1 kV |
| Input Voltage (Max) | 26.4 V |
| Input Voltage (Min) | 21.6 V |
| Input Voltage (DC Max) | 26.4 V |
| Input Voltage (DC Min) | 21.6 v |
| Output Current (Max) | 200 mA |
| Input Power (Max) | 1 W |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Input Voltage | 21.6V ~ 26.4V |
| expand all | |
| Size-Length | 11.48 mm |
| Size-Width | 6 mm |
| Size-Height | 10 mm |
| Weight | 1.3 g |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/12/17 |
Product Description
- The MEE1 series isolated single-output PCB-mounting DC/DC Converter with free air convection cooling. The device is more efficient and offers improved regulation performance for applications where a wide output voltage variation cannot be tolerated. This is ideally suited for providing local supplies on control system boards with the added benefit of 1kVDC galvanic isolation to reduce switching noise.
- Operation to zero load
- 1kVDC Isolation hi pot test
- Efficiency up to 87% typical
