MOC3011M ,Optocoupler, Optoisolator - Fairchild

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

123 points

Part No

MOC3011M
Manufacturer

Fairchild
ChipWorker Part#

CW15868333
Category

Optocoupler, Optoisolator
Package

DIP-6
Description

MOC3011 Series 1Channel 250V 7500Vrms Triac Optocoupler Through Hole-DIP-6
Documentation

Datasheet
Ships from

Moscow
Наличие

102400 pcs In Stock
Estimated Price

$ 0.17

Buy MOC3011M

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

MOC3011M Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

MOC3011M Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	MOC3011M
Manufacturer	Fairchild
ChipWorker Part#	CW15868333
Category	Optocoupler, Optoisolator
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	6 Pin
Case/Package	DIP-6
Input Voltage (DC)	1.15 V
Output Voltage	250 V, 250 V (max)
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	6 Position
Forward Voltage	1.15 V
Input Current	10.0 mA
Power Dissipation	330 mW
Isolation Voltage	5.3 kV
Holding Current	100 µA
Forward Current	60 mA
Input Voltage (Max)	1.5 V
Output Voltage (Max)	175 VAC
Reverse Breakdown Voltage	3 V
Maximum Forward Voltage (Max)	1.5 V
Forward Current (Max)	60 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	330 mW
Input Voltage	1.15 V
	expand all
Size-Length	8.89 mm
Size-Width	6.6 mm
Size-Height	3.53 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The MOC3011-M is a random-phase Triac Driver Output Optocoupler contains GaAs infrared emitting diode and a light activated silicon bilateral switch, which functions like a triac. It is designed for interfacing between electronic controls and power triacs to control resistive and inductive loads for 115VAC operations.
IR emitting diodes has low degradator excellent IFT stability
