NCP81074BDR2G - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

NCP81074BDR2G
Manufacturer

ON Semiconductor
ChipWorker Part#

CW22677076
Category

FET Driver
Package

SOIC-8
Description

Small, High Speed Low Side MOSFET Driver with 10A sink/source capability Single Channel 10A Low Side MOSFET Driver with CMOS thresholds in SO8, 2500-REEL
Documentation

Datasheet

NCP81074BDR2G Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

NCP81074BDR2G Specifications

Attribute	Attribute Value

Part Number	NCP81074BDR2G
Manufacturer	ON Semiconductor
ChipWorker Part#	CW22677076
Category	FET Driver
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	4.50V (min)
Rise/Fall Time	4 ns
Number of Outputs	2 Output
Number of Positions	8 Position
Rise Time	7 ns
Fall Time	7 ns
Fall Time (Max)	4 ns
Fall Time (Max)	4 ns
Operating Temperature (Max)	140 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	4.5V ~ 20V
Supply Voltage (Max)	20 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The NCP81074BDR2G is a small, high speed, low side MOSFET driver with 10A sink/source capability in 8 pin SOIC package. This single channel, low side MOSFET driver is capable of providing large peak currents into capacitive loads. It can deliver 7A peak current at the miller plateau region to help reduce miller effect during MOSFETs switching transitions. The device exhibits a split output configuration allowing the user to control the turn on and turn off slew rates. It is typically used in isolated bricks, telecom, data centre equipments and secondary synchronous rectifier, server power, telecommunication, data centre power, switch mode power supply, DC to DC converter and power factor correction applications.
High current drive capability reduce switching losses, VDD based threshold input type
Dual input design allows differential input signal for more control
High current drive capability of ±10A
TTL/CMOS compatible inputs independent of supply voltage
High reverse current capability of 10A peak
4ns typical rise and 4ns typical fall times with 1.8nF load
Fast propagation delay time of 15ns with input falling and 15ns with input rising
Input voltage range from 4.5V to 20V
Split output configuration dual input design offering drive flexibility
Operating temperature range from -40°C to 140°C
