The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

NMK1215SC
Manufacturer

muRata
ChipWorker Part#

CW49158263
Category

DC to DC Converter, DC/DC Converter
Package

SIP-7
Description

Module DC-DC 12Vin 2Out 15V/-15V 0.067A/-0.67A 2W 5Pin SIP Tube
Documentation

Datasheet

NMK1215SC Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

NMK1215SC Specifications

Attribute	Attribute Value

Part Number	NMK1215SC
Manufacturer	muRata
ChipWorker Part#	CW49158263
Category	DC to DC Converter, DC/DC Converter
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	5 Pin
Case/Package	SIP-7
Supply Voltage (DC)	12.0 V
Power Rating	2 W
Number of Outputs	2 Output
Input Voltage (DC)	10.8V ~ 13.2V
Output Voltage	±15 V
Output Current	67.0 mA
Flammability Rating	UL 94 V-0
Output Power	2 W
Isolation Voltage	3 kV
Input Voltage (Max)	13.2 V
Input Voltage (Min)	10.8 V
Input Voltage (DC Max)	13.2 V
Input Voltage (DC Min)	10.8 v
Output Current (Max)	67mA, 67mA
Input Power (Max)	2 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	10.8V ~ 13.2V
	expand all
Size-Length	19.5 mm
Size-Width	7.65 mm
Size-Height	10.15 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The NMK1215SC is a 2-output 2W board-mount isolated DC/DC Converter offers a power upgrade path from the 1W NMV series. The un-regulated device has superior output voltage set point accuracy in conjunction with excellent load regulation for this converter type. Unbalanced loading capabilities on dual output variants, all of the rated output power may be drawn from a single output.
No heat sink required
Industry standard pin-out
Fully encapsulated with toroidal magnetics
No electrolytic or tantalum capacitors
3kVDC Isolation (1 minute) hi pot test
Power density 1.31W/cm³
2.4% Maximum load regulation
20mVp-p Maximum ripple and noise
87% Typical efficiency
57pF Isolation capacitance
