OPA376AIDR - TI
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoOPA376AIDR
-
ManufacturerTI
-
ChipWorker Part#CW46234265
-
CategoryOperational Amplifier, OP Amp IC
-
PackageSOIC-8
-
DescriptionTEXAS INSTRUMENTS OPA376AIDR Operational Amplifier, Single, 1 Amplifier, 5.5MHz, 2V/µs, 2.2V to 5.5V, SOIC, 8Pins
-
DocumentationDatasheet
Payment Methods and Delivery
{{ estimate }}
OPA376AIDR Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
- |
{{outStock}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
- | ${{UpToFourDecimals(priceCalc,skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
{{ apiText }}{{ apiTime }}(UTC+8)
OPA376AIDR Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | OPA376AIDR |
| Manufacturer | TI |
| ChipWorker Part# | CW46234265 |
| Category | Operational Amplifier, OP Amp IC |
| Documentation | Datasheet |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | SOIC-8 |
| Supply Current | 760 µA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Common Mode Rejection Ratio | 76 dB |
| Input Offset Drift | 320 nV/K |
| Bandwidth | 5.5 MHz |
| Slew Rate | 2.00 V/μs |
| Gain Bandwidth Product | 5.5 MHz |
| Input Offset Voltage | 5 µV |
| Input Bias Current | .2 pA |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Gain Bandwidth | 5.5 MHz |
| Minimum CMRR Range | 76 dB |
| Supply Voltage | 2.2V ~ 5.5V |
| Supply Voltage (Max) | 5.5V ~ 6V |
| expand all | |
| Size-Height | 1.5 mm |
| Operating Temperature | -40℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2015/06/15 |
| ECCN Code | EAR99 |
Product Description
- DESCRIPTION
- The OPA376 family represent a new generation of low-noise operational amplifiers with e-trim, offering outstanding dc precision and ac performance. Rail-to-rail output, low offset (25mV max), low noise (7.5nV/√Hz), quiescent current of 950mA max, and a 5.5MHz bandwidth make this part very attractive for a variety of precision and portable applications. In addition, this device has a reasonably wide supply range with excellent PSRR, making it attractive for applications that run directly from batteries without regulation.
- The OPA376 (single version) is available in MicroSIZE SC70-5, SOT23-5, and SO-8 packages.
- The OPA2376 (dual) is offered in the WCSP-8, MSOP-8, and SO-8 packages. The OPA4376 (quad)
- is offered in a TSSOP-14 package. All versions are specified for operation from –40°C to +125°C.
- FEATURES
- • LOW NOISE: 7.5nV/√Hz at 1kHz
- • 0.1Hz TO 10Hz NOISE: 0.8mVPP
- • QUIESCENT CURRENT: 760mV (typ)
- • LOW OFFSET VOLTAGE: 5mV (typ)
- • GAIN BANDWIDTH PRODUCT: 5.5MHz
- • RAIL-TO-RAIL OUTPUT
- • SINGLE-SUPPLY OPERATION
- • SUPPLY VOLTAGE: 2.2V to 5.5V
- • SPACE-SAVING PACKAGES:
- – SC-70, SOT23, WCSP, MSOP, TSSOP
- APPLICATIONS
- • ADC BUFFER
- • AUDIO EQUIPMENT
- • MEDICAL INSTRUMENTATION
- • HANDHELD TEST EQUIPMENT
- • ACTIVE FILTERING
- • SENSOR SIGNAL CONDITIONING
