OPA548T ,Operational Amplifier, OP Amp IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

243 points

Part No

OPA548T
Manufacturer

TI
ChipWorker Part#

CW1391863
Category

Operational Amplifier, OP Amp IC
Package

TO-220-7
Description

Operational Amplifier, Single, 1 Amplifier, 1MHz, 10V/µs, ± 4V to ± 30V, TO-220, 7Pins
