PCM1803ADBR - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

PCM1803ADBR
Manufacturer

TI
ChipWorker Part#

CW3139680
Category

Analog to Digital, ADC IC
Package

SSOP-20
Description

TEXAS INSTRUMENTS PCM1803ADBR Analog to Digital Converter, 24Bit, 96KSPS, Single, 4.5V, 5.5V, SSOP
Documentation

Datasheet

PCM1803ADBR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

PCM1803ADBR Specifications

Attribute	Attribute Value

Part Number	PCM1803ADBR
Manufacturer	TI
ChipWorker Part#	CW3139680
Category	Analog to Digital, ADC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	SSOP-20
Supply Voltage (DC)	4.50V (min)
Supply Current	11.7 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Bits	24 Bit
Power Dissipation	77 mW
Sample Rate	96 Ksps
Power Consumption	77 mW
Number of ADCs	2 ADC
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	80 mW
Number of Input Channels	2 Channel
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
Input Voltage	3 V
	expand all
Size-Length	7.2 mm
Size-Width	5.3 mm
Size-Height	1.95 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The PCM1803A device is high-performance, low-cost, single-chip stereo analog-to-digital converter with single-ended analog voltage input. The PCM1803A uses a delta-sigma modulator with 64- and 128-times oversampling, and includes a digital decimation filter and high-pass filter, which removes the DC component of the input signal. For various applications, the PCM1803A supports master and slave modes and four data formats in serial interface. The PCM1803A is suitable for a wide variety of cost-sensitive consumer applications where good performance and operation from a 5-V analog supply and 3.3-V digital supply are required. The PCM1803A is fabricated using a highly-advanced CMOS process and is available in a small 20-pin SSOP package.
