REF195GRUZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

REF195GRUZ
Manufacturer

ADI
ChipWorker Part#

CW325404
Category

Voltage Reference
Package

TSSOP-8
Description

V-Ref Precision 5V 30mA 8Pin TSSOP Tube
Documentation

Datasheet

REF195GRUZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

REF195GRUZ Specifications

Attribute	Attribute Value

Part Number	REF195GRUZ
Manufacturer	ADI
ChipWorker Part#	CW325404
Category	Voltage Reference
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	TSSOP-8
Input Voltage (DC)	15.0V (max)
Output Voltage	5 V
Output Current	30 mA
Supply Current	45 µA
Number of Channels	1 Channel
Number of Positions	8 Position
Quiescent Current	45.0 µA
Input Voltage (Max)	18 V
Output Voltage (Max)	5.01 V
Output Voltage (Min)	5 V
Output Current (Max)	30 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	2 mV
Input Voltage	5.1V ~ 15V
	expand all
Size-Length	3 mm
Size-Width	4.4 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 85℃
Temperature Coefficient	±10 ppm/℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The REF195GRUZ is a Precision Micropower 5V Voltage Reference that uses a patented temperature drift curvature correction circuit and laser trimming of highly stable, thin-film resistors to achieve a very low temperature coefficient and high initial accuracy. The REF195 series is made up of micropower, low dropout voltage (LDV) devices, providing stable output voltage from supplies as low as 100mV above the output voltage and consuming less than 45µA of supply current. In sleep mode, which is enabled by applying a low TTL or CMOS level to the SLEEP pin, the output is turned off and supply current is further reduced to less than 15µA.
High output current (30mA)
Low supply current (45µA maximum)
15µA Maximum sleep mode
Low dropout voltage
4ppm/mA Load regulation
4ppm/V Line regulation
Short-circuit protection
ESD sensitive device, take proper precaution while handling the device.
