RP410024 - TE Connectivity

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

RP410024
Manufacturer

TE Connectivity
ChipWorker Part#

CW57533600
Category

Power Relay
Description

Power Relay 24VDC 20A SPDT (( 29mm 12.6mm 25.5mm)) Through Hole
Documentation

Datasheet

RP410024 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	-	6 - 8 {{delivery_date}}

RP410024 Specifications

Attribute	Attribute Value

Part Number	RP410024
Manufacturer	TE Connectivity
ChipWorker Part#	CW57533600
Category	Power Relay
Documentation	Datasheet
Mounting Style	Through Hole
Input Voltage (DC)	24.0 V
Contacts Type	SPDT
voltage rating	2.40 V
Contact Current Rating	12.0 A
Coil Voltage	24 VDC
Coil Current	21.8 mA
Coil Power (DC)	500 mW
Coil Resistance	1.1 kΩ
Carry Current	20.0 A
Coil Voltage (DC)	24 V
Coil Power	500 mW
Switching Current (Max)	20 A
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating	24 VDC
	expand all
Size-Length	29 mm
Size-Width	12.6 mm
Size-Height	25.5 mm
Contact Material	Silver Cadmium Oxide
Operating Temperature	-40℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Bar
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
ELV Compliant	Non-Compliant
HTS Code	8536410050
ECCN Code	EAR99

Product Description

**TE Connectivity RPII Series PCB Power Relay**
RPII series PCB power relays with 500mW coil power available with SPST, SPDT and DPDT contact configurations. Part numbers RP3-XXXX and RP4-XXXX are flux proof. Part numbers RP7-XXXX and RP8-XXXX are wash tight.
