RT114024 - TE Connectivity
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoRT114024
-
ManufacturerTE Connectivity
-
ChipWorker Part#CW7598804
-
CategoryPower Relay
-
Package-
-
DescriptionPower Relay 24VDC 12A SPDT (( 29mm 12.7mm 15.7mm)) Through Hole
-
DocumentationDatasheet
