SN74LV04ADRG4 ,Logic Control, Logic Gate IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

37 points

Part No

SN74LV04ADRG4
Manufacturer

TI
ChipWorker Part#

CW104125106
Category

Logic Control, Logic Gate IC
Package

SOIC-14
Description

Inverter 6Element CMOS 14Pin SOIC T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.23

Buy SN74LV04ADRG4

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

SN74LV04ADRG4 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

SN74LV04ADRG4 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	SN74LV04ADRG4
Manufacturer	TI
ChipWorker Part#	CW104125106
Category	Logic Control, Logic Gate IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Supply Voltage (DC)	2.00V ~ 5.50V
Output Current	12.0 mA
Number of Circuits	6 Circuit
Number of Bits	6 Bit
Propagation Delay Max (tpd)	8.50 ns
Voltage Nodes	5.00 V, 3.30 V, 2.50 V
Number of Inputs	6 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2 V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Similar & Replacement Parts

Similar products

Product Description

description
These hex inverters are designed for 2-V to 5.5-V VCC operation.
The SN74LV04A device contains six independent inverters.
Features
• 2-V to 5.5-V VCC Operation
• Max tpd of 6.5 ns at 5 V
• Latch-Up Performance Exceeds 250 mA Per JESD 17
• Typical VOLP(Output Ground Bounce) < 0.8 V at VCC= 3.3 V, TA= 25°C
• Typical VOHV(Output VOH Undershoot)> 2.3 V at VCC= 3.3 V, TA= 25°C
• Support Mixed-Mode Voltage Operation on All Ports
• Ioff Supports Partial-Power-Down Mode Operation
• ESD Protection Exceeds JESD 22
– 2000-V Human-Body Model
– 200-V Machine Model
– 1000-V Charged-Device Model
