SN74LVC1G07DBVR ,Logic Controller, Logic IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

290 points

Part No

SN74LVC1G07DBVR
Manufacturer

TI
ChipWorker Part#

CW49883
Category

Logic Controller, Logic IC
Package

SOT-23-5
Description

Buffer/Driver 1CH Non-Inverting Open Drain CMOS 5Pin SOT-23 T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

31537 pcs In Stock
Estimated Price

$ 0.03

Buy SN74LVC1G07DBVR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

SN74LVC1G07DBVR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

SN74LVC1G07DBVR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	SN74LVC1G07DBVR
Manufacturer	TI
ChipWorker Part#	CW49883
Category	Logic Controller, Logic IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	5 Pin
Case/Package	SOT-23-5
Supply Voltage (DC)	5.00 V, 5.50 V (max)
Number of Outputs	1 Output
Supply Current	40.0 mA
Number of Channels	1 Channel
Number of Positions	5 Position
Number of Bits	1 Bit
Propagation Delay Max (tpd)	3.50 ns
Voltage Nodes	5.00 V
Number of Gates	1 Gate
Number of Inputs	1 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	1.65V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	1.65 V
	expand all
Size-Length	3.05 mm
Size-Width	1.75 mm
Size-Height	1.3 mm
Operating Temperature	-40℃ ~ 125℃ (TA)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2018/06/27
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The SN74LVC1G07DBVR is a single Buffer/Driver IC is open drain and can be connected to other open-drain outputs to implement active-low wired-OR or active-high wired-AND functions. The maximum sink current is 32mA.
Supports 5V VCC Operation
Input and Open-Drain Output Accepts Voltage up to 5.5V
Can Translate Up or Down
4.2ns at 3.3V Maximum Propagation Delay Time
Low-power Consumption, 10µA Maximum ICC
±24mA Output Drive at 3.3V
Ioff Supports Live Insertion, Partial-power-down Mode and Back-drive Protection
Latch-up Performance Exceeds 100mA Per JESD 78, Class II
Green Product, No Sb/Br
Device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
