SN75472P ,Interface IC, Interface Controller - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

110 points

Part No

SN75472P
Manufacturer

TI
ChipWorker Part#

CW23421924
Category

Interface IC, Interface Controller
Package

PDIP-8
Description

Pref DRVR Dual 5V 1000mW 8Pin PDIP Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.05

Buy SN75472P

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

SN75472P Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

SN75472P Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	SN75472P
Manufacturer	TI
ChipWorker Part#	CW23421924
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	PDIP-8
Supply Voltage (DC)	5.00 V, 4.75 V (min)
Number of Outputs	2 Output
Output Voltage	70 V
Output Current	300 mA
Supply Current	76 mA
Power Dissipation	1 W
Drivers Per Package	2
Input Voltage (Max)	5.5 V
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	1 W
Supply Voltage	4.75V ~ 5.25V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	4.75 V
Input Voltage	5.5 V
	expand all
Size-Length	10.16 mm
Size-Width	6.6 mm
Size-Height	4.57 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The SN75472P is a dual high-voltage high-current Peripheral Driver functionally interchangeable with series SN75451B and series SN75461 peripheral drivers, but are designed for use in systems that require higher breakdown voltages than either of those series can provide at the expense of slightly slower switching speeds than series 75451B (limits are the same as series SN75461). Typical applications include high-speed logic buffers, power drivers, relay drivers, lamp drivers, MOS drivers, line drivers and memory drivers. The SN75472 is dual peripheral AND, NAND or and NOR driver, respectively, (assuming positive logic), with the output of the logic gates internally connected to the bases of the NPN output transistors.
High-voltage outputs
Medium-speed switching
Circuit flexibility for varied applications and choice of logic function
TTL-compatible diode-clamped inputs
Standard supply voltage
Plastic DIP (P) with copper lead frame for cooler operation and improved reliability
