STD45NF75T4 - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

STD45NF75T4
Manufacturer

ST Microelectronics
ChipWorker Part#

CW39312848
Category

MOSFET, MOSFET Transistor
Package

TO-252-3
Description

DPAK N-CH 75V 40A
Documentation

Datasheet

STD45NF75T4 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

STD45NF75T4 Specifications

Attribute	Attribute Value

Part Number	STD45NF75T4
Manufacturer	ST Microelectronics
ChipWorker Part#	CW39312848
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	TO-252-3
Voltage Rating (DC)	75.0 V
Current Rating	40.0 A
Number of Channels	1 Channel
Drain to Source Resistance (on) (Rds)	0.018 Ω
Polarity	N-Channel
Power Dissipation	125 W
Threshold Voltage	4 V
Input Capacitance	1760 pF
Drain to Source Voltage (Vds)	75 V
Breakdown Voltage (Drain to Source)	75.0 V
Breakdown Voltage (Gate to Source)	±20.0 V
Continuous Drain Current (Ids)	20.0 A
Rise Time	40 ns
Input Capacitance (Ciss)	1760pF @25V(Vds)
Input Power (Max)	125 W
Fall Time	12 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	125W (Tc)
	expand all
Size-Length	6.6 mm
Size-Width	6.2 mm
Size-Height	2.4 mm
Operating Temperature	-55℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC

Product Description

The STD45NF75T4 is a STripFET™ II N-channel Power MOSFET developed using STMicroelectronics unique Single Feature Size™ strip-based process. The device has extremely high packing density for low ON-resistance, rugged avalanche characteristics and less critical alignment steps therefore a remarkable manufacturing reproducibility.
100% Avalanche tested
Gate charge minimized
-55 to 175°C Operating junction temperature range
