STM32L476RCT6 ,Microcontroller, MCU IC - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

136 points

Part No

STM32L476RCT6
Manufacturer

ST Microelectronics
ChipWorker Part#

CW4190396
Category

Microcontroller, MCU IC
Package

LQFP-64
Description

MCU 32Bit ARM Cortex M4 RISC 256KB Flash 1.8V/2.5V/3.3V 64Pin LQFP Tray
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 3.66

Buy STM32L476RCT6

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

STM32L476RCT6 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

STM32L476RCT6 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	STM32L476RCT6
Manufacturer	ST Microelectronics
ChipWorker Part#	CW4190396
Category	Microcontroller, MCU IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	64 Pin
Case/Package	LQFP-64
Frequency	80 MHz
Operating Voltage	1.71V ~ 3.6V
Number of Positions	64 Position
Clock Speed	80.0 MHz
RAM Memory Size	128 KB
Number of Bits	32 Bit
Power Dissipation	444 mW
Number of ADCs	3 ADC
Number of Inputs and Outputs	51 Input IO
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	444 mW
Number of DACs	1 DAC
Supply Voltage	1.71V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	1.71 V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	3A991A2

Similar & Replacement Parts

Similar products

Product Description

The STM32L476RCT6 is an ultra-low-power STM32 L4 series 32-bit Microcontroller based on the high-performance ARM Cortex-M4 RISC core operating at a frequency of up to 80MHz. The Cortex-M4 core features a floating point unit (FPU) single precision which supports all ARM single-precision data-processing instructions and data types. It also implements a full set of DSP instructions and a memory protection unit (MPU) which enhances application security. The device embed high-speed memories (Flash memory up to 256KB, up to 128kB of SRAM), a quad SPI flash memories interface and an extensive range of enhanced I/Os and peripherals connected to two APB buses, two AHB buses and a 32-bit multi-AHB bus matrix. The device embed several protection mechanisms for embedded flash memory and SRAM - readout protection, write protection, proprietary code readout protection and firewall.
100 DMIPS/1.25DMIPS/MHz (Dhrystone 2.1)
4 to 48MHz Crystal oscillator
32kHz Crystal oscillator for RTC (LSE)
Internal 16MHz factory-trimmed RC (±1%)
Internal low-power 32kHz RC (±5%)
Internal multispeed 100kHz to 48MHz oscillator, auto-trimmed by LSE
3 PLLs for system clock, USB, audio, ADC
RTC with HW calendar, alarms and calibration
LCD controller
Up to 24 capacitive sensing channels - Support touchkey, linear and rotary touch sensors
SysTick Timer
2 x Watchdog timers
4 x Digital filters for sigma delta modulator
USB OTG 2.0 full speed, LPM and BCD peripheral
2 x Serial audio interface
CAN (2.0B Active) and SDMMC interface
SWPMI single wire protocol master I/F
14-channel DMA Controller
True random number generator
CRC calculation unit, 96-bit unique ID
