STM8A-DISCOVERY ,Microprocessor Primary Platform - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

105 points

Part No

STM8A-DISCOVERY
Manufacturer

ST Microelectronics
ChipWorker Part#

CW4496759
Category

Microprocessor Primary Platform
Description

STM8AF5288T/STM8AL3L68T Microcontroller Board 16MHz CPU 1KB/2KB/32KB/64KB EEPROM/Flash
Documentation

Datasheet
Ships from

Moscow
Наличие

14 pcs In Stock
Estimated Price

$ 26.85

Buy STM8A-DISCOVERY

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

STM8A-DISCOVERY Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

STM8A-DISCOVERY Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	STM8A-DISCOVERY
Manufacturer	ST Microelectronics
ChipWorker Part#	CW4496759
Category	Microprocessor Primary Platform
Documentation	Datasheet
Number of Bits	8 Bit
	expand all
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
ECCN Code	3A991A2

Similar & Replacement Parts

Similar products

Product Description

STM8A-DISCOVERY helps user discover the STM8AF5288 and STM8AL3L68 automotive microcontroller features and develop applications through two dedicated application boards that can be connected together via a LIN network. The STM8AF board can perform both CAN and LIN communications with the MCU powered at 5V and is ready to be connected into a network with its integrated transceiver. The STM8AL board manages LIN slave communication through its transceiver and uses a 4 digit alphanumeric LCD display with the MCU powered at 3.3V, offering low energy power modes. Both STM8AF and STM8AL boards include push buttons, LEDs, external connectors and allow various configurations to take advantage of the numerous capabilities of the microcontrollers.
On board ST-LINK/V2 included for debugging and programming
Board power supply through 5V USB bus
Internal dual ST662A step up converter building the 12Vdc when powered by USB port
L99PM62GXP power management IC with LIN & CAN with SPI control interface & high side drivers
Extension header for L99PM62GXP including relays, high side outputs and wake up capabilities
STM8AF5288T MCU featuring 64Kbytes Flash, 2Kbytes data EEPROM, LIN, CAN in an 48 pin package
STM8AL3L68T MCU featuring 32Kbytes Flash, 1Kbytes data EEPROM, LCD in an 48 pin package
4 digit alphanumeric LCD display including 4 bars display
Extension header for MCU connectivity
16MHz HSE XTAL crystal oscillator
