STMPS2171MTR - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

STMPS2171MTR
Manufacturer

ST Microelectronics
ChipWorker Part#

CW36029067
Category

Power Management IC
Package

SOIC-8
Description

Current Limit SW 1IN 1Out 2.7V to 5.5V 1A 8Pin SO N T/R
Documentation

Datasheet

STMPS2171MTR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

STMPS2171MTR Specifications

Attribute	Attribute Value

Part Number	STMPS2171MTR
Manufacturer	ST Microelectronics
ChipWorker Part#	CW36029067
Category	Power Management IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Operating Voltage	5.50V (max)
Number of Outputs	1 Output
Output Current	1 A
Supply Current	0.04 mA
Number of Positions	8 Position
Power Dissipation	0.135 W
Input Voltage (Max)	5.5 V
Input Voltage (Min)	2.7 V
Output Current (Max)	1 A
Output Current (Min)	0 A
Number of Inputs	1 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	135 mW
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
Input Voltage	2.7V ~ 5.5V
	expand all
Operating Temperature	-40℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

Description
The STMPS2141, STMPS2151, STMPS2161, STMPS2171 power distribution switches are intended for applications where heavy capacitive loads and short circuits are likely to be encountered. These devices incorporate 90 mΩ N-channel MOSFET high-side power switches for power-distribution. These switches are controlled by a logic enable input.
Features
■ 90 mΩhigh-side MOSFET switch
■ 500/1000 mA continuous current
■ Thermal and short-circuit protection with overcurrent logic output
■ Operating range from 2.7 V to 5.5 V
■ CMOS- and TTL-compatible enable inputs
■ Undervoltage lockout (UVLO)
■ 12µA maximum standby supply current
■ Ambient temperature range, -40°C to 85°C
■ 8 kV ESD protection
■ Reverse current protection
■ Fault-blanking
