STN3NF06 ,MOSFET, MOSFET Transistor - ST Microelectronics
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
106 points
-
Part NoSTN3NF06
-
ManufacturerST Microelectronics
-
ChipWorker Part#CW20198303
-
CategoryMOSFET, MOSFET Transistor
-
PackageTO-261-4
-
DescriptionTrans MOSFET N-CH 60V 4A 4Pin(3+Tab) SOT-223 T/R
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие77195 pcs In Stock
-
Estimated Price$ 0.08
