STPS4045CW - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

STPS4045CW
Manufacturer

ST Microelectronics
ChipWorker Part#

CW1621475
Category

Schottky Diode
Package

TO-247-3
Description

Diode Schottky 45V 40A 3Pin(3+Tab) TO-247 Tube
Documentation

Datasheet

STPS4045CW Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

STPS4045CW Specifications

Attribute	Attribute Value

Part Number	STPS4045CW
Manufacturer	ST Microelectronics
ChipWorker Part#	CW1621475
Category	Schottky Diode
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-247-3
Voltage Rating (DC)	45.0 V
Current Rating	40.0 A
Forward Voltage	0.94 V
Forward Current	40 A
Max Forward Surge Current (Ifsm)	220 A
Maximum Forward Voltage (Max)	760mV @20A
Forward Current (Max)	40 A
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	175℃ (Max)
	expand all
Size-Length	15.75 mm
Size-Width	5.15 mm
Size-Height	20.15 mm
Operating Temperature	-65℃ ~ 175℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

Diode Array 1 Pair Common Cathode Schottky 45V 20A Through Hole TO-247-3
