TAS5086DBT ,Active Chip - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

150 points

Part No

TAS5086DBT
Manufacturer

TI
ChipWorker Part#

CW27030500
Category

Active Chip
Package

TSSOP-38
Description

TEXAS INSTRUMENTS TAS5086DBT. Audio Control, Digital Audio Interface, 3V to 3.6V, I2C, Serial, TSSOP, 38Pins, 0 °C
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 7.86

Buy TAS5086DBT

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TAS5086DBT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TAS5086DBT Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TAS5086DBT
Manufacturer	TI
ChipWorker Part#	CW27030500
Category	Active Chip
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	38 Pin
Case/Package	TSSOP-38
Number of Channels	6 Channel
Number of Positions	38 Position
Power Dissipation	817.16 mW
Output Power	817 mW
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage	3V ~ 3.6V
	expand all
Size-Height	1.05 mm
Operating Temperature	0℃ ~ 70℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The TAS5086DBT is a 6-channel Digital Pulse-Width Modulator provides both advanced performance and a high level of system integration. It is designed to interface seamlessly with most audio digital signal processors and MPEG decoders, accepting a wide range of input data and clock formats. The TAS5086 drives six channels of speakers in either single-ended or bridge-tied load configurations that accept a 1N + 1 interface format. The TAS5086 also supports 2N + 1 power stages with the use of some external logic (e.g., TAS5112). Stereo line out in I2S format is available with either a pass-through signal (SDIN4) or an internal down mix. It uses AD modulation operating at a 384kHz switching rate for 32, 44.1, 48, 88.2, 96, 176.4 and 192kHz data. The 8x oversampling, combined with the 4th-order noise shaper, provides a broad, flat noise floor and excellent dynamic range from 20Hz to 20kHz.
Audio input/output
Four serial audio inputs (eight channels)
Any output channel can be mapped to any output pin
Supports single-ended and bridge-tied loads
Integrated bass management
Two programmable biquads in subwoofer channel
Selectable DC blocking filters
Automated operation with easy-to-use control interface
Control interface operational without MCLK
Green product and no Sb/Br
