TLE4678EL - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TLE4678EL
Manufacturer

Infineon
ChipWorker Part#

CW70226667
Category

Voltage Regulator
Package

SSOP-14
Description

LDO Regulator Pos 5V 0.2A Automotive 14Pin SSOP T/R
Documentation

Datasheet

TLE4678EL Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	-	6 - 8 {{delivery_date}}

TLE4678EL Specifications

Attribute	Attribute Value

Part Number	TLE4678EL
Manufacturer	Infineon
ChipWorker Part#	CW70226667
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SSOP-14
Number of Outputs	1 Output
Output Voltage	5 V
Output Current	200 mA
voltage rating	0.165V @150mA
Input Voltage (Max)	45 V
Input Voltage (Min)	3.3 V
Output Voltage (Min)	5 V
Output Current (Max)	0.2 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	±2 %
Input Voltage	≤45 V
	expand all
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Unknown
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

Description:
The TLE4678 is a monolithic integrated low dropout fixed output voltage regulator for loads up to 200 mA. An input voltage of up to 45 V is regulated to an output voltage of 5 V. The integrated reset and watchdog function, as well as several protection circuits, combined with a wide operating temperature range offered by the TLE4678 make it suitable for supplying microprocessor systems in automotive environments.The watchdog circuitry will be disabled in case the output current drops below a programmable threshold, enabling a microcontroller to switch in stand-by mode. Modifying the reset threshold is possible by an optional resistor divider. The TLE4678 is available in a PG-DSO-14 package which makes it pin-compatible to the TLE4278 as well as in a small thermally enhanced PG-SSOP-14 exposed pad package.
Summary of Features:
Output Voltage 5 V ± 2%
Current Capability 200 mA
Ultra Low Current Consumption
Very Low Dropout Voltage
Watchdog Circuit for Monitoring a Microprocessor with Programmable Load-dependent Activating Threshold
Reset Circuit Sensing the Output Voltage with Programmable Switching Threshold and Delay Time
Reset Output Active Low Down to V Q = 1 V
Separated Reset and Watchdog Output
Excellent Line Transient Robustness
Maximum Input Voltage -42 V ≤ V I ≤ +45 V
Reverse Polarity Protection
Short Circuit Protected
Overtemperature Shutdown
Automotive Temperature Range -40 °C ≤ T j ≤ 150 °C
Available in a small thermally enhanced PG-SSOP-14 package
Green Product (RoHS Compliant)
AEC Qualified
Benefits:
Robust Protection Features
Wide Input Operation and Temperature Range
