TLV320AIC3007IRSBT - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TLV320AIC3007IRSBT
Manufacturer

TI
ChipWorker Part#

CW14473121
Category

CODEC
Package

WQFN-40
Description

Audio Codec 2ADC / 2DAC 40Pin WQFN EP T/R
Documentation

Datasheet

TLV320AIC3007IRSBT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TLV320AIC3007IRSBT Specifications

Attribute	Attribute Value

Part Number	TLV320AIC3007IRSBT
Manufacturer	TI
ChipWorker Part#	CW14473121
Category	CODEC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	40 Pin
Case/Package	WQFN-40
Number of Channels	12 Channel
Number of Positions	40 Position
Power Dissipation	2350 mW
Sample Rate	96 KSPS
Power Consumption	15.0 mW
Bandwidth	20 kHz
Number of ADCs	2 ADC
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	2350 mW
Number of Input Channels	7 Channel
Number of Output Channels	6 Channel
Number of DACs	2 DAC
	expand all
Size-Length	5.15 mm
Size-Width	5.15 mm
Size-Height	0.75 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The TLV320AIC3007IRSBT is a low power stereo Audio Codec with stereo headphone amplifier and mono class-D speaker driver, as well as multiple inputs and outputs programmable in single-ended or fully differential configurations. Extensive register-based power control is included, enabling stereo 48kHz DAC playback as low as 15mW from a 3.3V analog supply. The record path of the TLV320AIC3007 contains integrated microphone bias, digitally controlled stereo microphone preamplifier and automatic gain control (AGC), with mix/mux capability among the multiple analog inputs. Programmable filters are available during record which can remove audible noise that can occur during optical zooming in digital cameras. The playback path includes mix/mux capability from the stereo DAC and selected inputs, through programmable volume controls, to the various outputs. It contains three high-power output drivers as well as two single-ended line output drivers and a differential class-D output driver.
Stereo codec with integrated mono Class-D amplifier
High performance audio DAC
Flexible power saving modes and performance are available
High performance audio ADC
Capability for floating input configurations
Single-ended stereo line outputs
Ultralow power mode with passive analog bypass
Programmable input/output analog gains
Automatic gain control (AGC) for record
Programmable microphone bias level
Programmable PLL for flexible clock generation
I²C Control bus
Green product and no Sb/Br
Device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
