TNY255PN - Power Integrations

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TNY255PN
Manufacturer

Power Integrations
ChipWorker Part#

CW2260340
Category

AC to DC Converter, AC/DC Power Module
Package

DIP-8
Description

AC-DC Power Conversion - TinySwitch Family 6.5W 85-265VAC 10W 100/115/230VAC
Documentation

Datasheet

TNY255PN Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TNY255PN Specifications

Attribute	Attribute Value

Part Number	TNY255PN
Manufacturer	Power Integrations
ChipWorker Part#	CW2260340
Category	AC to DC Converter, AC/DC Power Module
Documentation	Datasheet
Mounting Style	Through Hole
Case/Package	DIP-8
Frequency	130 kHz
Supply Voltage (DC)	325V (max)
Power Rating	6.5 W
Output Voltage	700 V
Output Current	530 mA
Breakdown Voltage	700 V
Supply Current	215 µA
Output Power	6.5 W
Switching Frequency	130 kHz
Duty Cycle	67 %
Maximum Duty Cycle	67 %
Input Voltage	85.265 V
	expand all
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Not For New Designs
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

Converter Offline Flyback Topology 130kHz 8-DIP
