TPD3S044DBVR - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TPD3S044DBVR
Manufacturer

TI
ChipWorker Part#

CW42811993
Category

Power Management IC
Package

SOT-23-6
Description

Current Limit SW 2IN 1Out 5V 1.5A 6Pin SOT-23 T/R
Documentation

Datasheet

TPD3S044DBVR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TPD3S044DBVR Specifications

Attribute	Attribute Value

Part Number	TPD3S044DBVR
Manufacturer	TI
ChipWorker Part#	CW42811993
Category	Power Management IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	SOT-23-6
Supply Voltage (DC)	4.50V (min)
Capacitance	1.40 pF
Number of Outputs	1 Output
Output Current	1.5 A
Rise Time	640 µs
Input Voltage (Max)	5.5 V
Input Voltage (Min)	4.5 V
Output Current (Max)	1.5 A
Number of Inputs	2 Input
Fall Time	400 µs
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
Input Voltage	4.5V ~ 5.5V
	expand all
Size-Length	3.05 mm
Size-Width	1.75 mm
Size-Height	1.3 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

Applications
• USB Ports/Hubs
• Laptops, Desktops
• High-Definition Digital TVs
• Set Top Boxes
