TPS2546RTER - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TPS2546RTER
Manufacturer

TI
ChipWorker Part#

CW1540900
Category

Power Distribution
Package

WQFN-16
Description

USB Power Distribution Sw Single 5.5V 0.2A to 2.5A 16Pin WQFN T/R
Documentation

Datasheet

TPS2546RTER Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TPS2546RTER Specifications

Attribute	Attribute Value

Part Number	TPS2546RTER
Manufacturer	TI
ChipWorker Part#	CW1540900
Category	Power Distribution
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	WQFN-16
Number of Outputs	1 Output
Input Voltage (DC)	5.50 V
Output Current	2.5 A
Number of Positions	16 Position
Output Current (Max)	3 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
Input Voltage	5.5 V
	expand all
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

* D+/D– CDP/DCP Modes per USB Battery Charging Specification 1.2 * D+/D– Shorted Mode per Chinese Telecommunication Industry Standard YD/T 1591-2009 * Supports non-BC1.2 Charging Modes by Automatic Selection * D+/D– Divider Modes 2.0V/2.7V and 2.7/2.0V * D+/D&– 1.2V Mode * Supports Sleep-Mode Charging and Mouse/Keyboard Wake Up * Automatic SDP/CDP Switching for Devices That do not Connect to CDP Ports * Load Detection for Power Supply Control in S4/S5 Charging and Port Power Management in all Charge Modes * Compatible with USB 2.0 and 3.0 Power Switch requirements * Integrated 73-mΩ (typ) High-Side MOSFET * Adjustable Current-Limit up to 3 A (typ) * Operating Range: 4.5 V to 5.5 V * Max Device Current * 2 µA When Device Disabled * 270 µA When Device Enabled * Drop-In and BOM Compatible with TPS2543 * Available in 16-Pin QFN (3x3) Package * 8KV ESD Rating on DM/DP Pins * UL Listed and CB File No. E169910
