TPS5430DDA ,DC to DC Converter - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

272 points

Part No

TPS5430DDA
Manufacturer

TI
ChipWorker Part#

CW30859
Category

DC to DC Converter
Package

SOIC-8
Description

Step-Down Regulator 5.5V to 36V, 3A, 500kHz Step Down SWIFT Converter Conv DC-DC 5.5V to 36V Step Down Single-Out 1.22V to 31V 3A 8Pin HSOP EP Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

218 pcs In Stock
Estimated Price

$ 0.44

Buy TPS5430DDA

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TPS5430DDA Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TPS5430DDA Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TPS5430DDA
Manufacturer	TI
ChipWorker Part#	CW30859
Category	DC to DC Converter
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Frequency	500 kHz
Supply Voltage (DC)	36.0V (max)
Number of Outputs	1 Output
Output Voltage	31 V
Output Current	3 A
Number of Channels	1 Channel
Number of Positions	8 Position
Quiescent Current	3 mA
Number of Regulated Outputs	1 Output
Switching Frequency	500 kHz
Thermal Shutdown	Yes
Topology	Buck
Input Voltage (Max)	36 V
Input Voltage (Min)	5.5 V
Output Voltage (Max)	31 V
Output Voltage (Min)	1.22 V
Output Current (Max)	3 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	5.5 V
Supply Voltage (Min)	5.5 V
Input Voltage	5.5V ~ 36V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.55 mm
Weight	0.001129445076 kg
Operating Temperature	-40℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/12/17
HK STC License	NLR

Similar & Replacement Parts

Similar products

Product Description

The TPS5430DDA is a 3A 500kHz Step-down Converter with Eco-mode™ that integrates a low-resistance, high-side N-channel MOSFET. Included on the substrate with the listed features are a high-performance voltage error amplifier that provides tight voltage regulation accuracy under transient conditions, an under-voltage-lockout circuit to prevent start-up until the input voltage reaches 5.5V, an internally set slow-start circuit to limit inrush currents and a voltage feed-forward circuit to improve the transient response. Using the ENA pin, shutdown supply current is reduced to 18µA typically. Other features include an active-high enable, over-current limiting, over-voltage protection and thermal shutdown. To reduce design complexity and external component count, the TPS5430 feedback loop is internally compensated. The TPS5430 regulates a wide variety of power sources including 24V bus.
Up to 3A continuous (4A peak) output current
High efficiency up to 95% enabled by 110mR integrated MOSFET switch
Wide output voltage range (adjustable down to 1.22V with 1.5% initial accuracy)
Internal compensation minimizes external parts count
Improved line regulation and transient response by input voltage feed-forward
System protected by over-current limiting, overvoltage protection and thermal shutdown
Green product and no Sb/Br
This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
