TPS56221DQPT - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TPS56221DQPT
Manufacturer

TI
ChipWorker Part#

CW2315896
Category

DC to DC Converter
Package

QFN-22
Description

Conv DC-DC 4.5V to 14V Step Down Single-Out 0.6V to 12V 25A 22Pin SON EP T/R
Documentation

Datasheet

TPS56221DQPT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TPS56221DQPT Specifications

Attribute	Attribute Value

Part Number	TPS56221DQPT
Manufacturer	TI
ChipWorker Part#	CW2315896
Category	DC to DC Converter
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	22 Pin
Case/Package	QFN-22
Number of Outputs	1 Output
Output Voltage	0.6V ~ 12V
Output Current	25 A
Number of Positions	22 Position
Quiescent Current	2.50 mA
Number of Regulated Outputs	1 Output
Switching Frequency	1.1 MHz
Topology	Buck
Input Voltage (Max)	14 V
Input Voltage (Min)	4.5 V
Output Voltage (Max)	12 V
Output Voltage (Min)	600 mV
Output Current (Max)	25 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	4.5 V
Input Voltage	4.5V ~ 14V
	expand all
Operating Temperature	-40℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Product Description

The TPS56221DQPT is a high-efficiency and high-current synchronous Buck Converter designed to operate from a supply of 4.5 to 14V. The device can produce an output voltage as low as 0.6V at loads up to 25A. Integrated NexFET™ power MOSFETs provide a small footprint and ease of use. The device implements a voltage-mode control with voltage feed-forward compensation that responds instantly to input voltage change. The device offers design flexibility with a variety of user programmable functions, including soft-start, overcurrent protection (OCP) levels and loop compensation. OCP levels are programmed by a single external resistor connected from the ILIM pin to the circuit ground. During the initial power-ON sequence, the device enters a calibration cycle, measures the voltage at the ILIM pin and sets an internal OCP voltage level.
