TPS61072DDCR - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TPS61072DDCR
Manufacturer

TI
ChipWorker Part#

CW28808596
Category

DC to DC Converter
Package

TSOT-23-6
Description

Step-Up Regulator Adjustable, 600mA Switch, 90% Efficient PFM/PWM Boost Converter in ThinSOT-23 Conv DC-DC 0.9V to 5.5V Step Up Single-Out 1.8V to 5.5V 0.15A 6Pin TSOT-23 T/R
Documentation

Datasheet

TPS61072DDCR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TPS61072DDCR Specifications

Attribute	Attribute Value

Part Number	TPS61072DDCR
Manufacturer	TI
ChipWorker Part#	CW28808596
Category	DC to DC Converter
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	TSOT-23-6
Supply Voltage (DC)	5.50V (max)
Number of Outputs	1 Output
Output Voltage	1.8V ~ 5.5V
Output Current	600 mA
Supply Current	19.0 µA
Quiescent Current	19.0 µA
Number of Regulated Outputs	1 Output
Switching Frequency	600 kHz
Topology	Boost
Input Voltage (Max)	5.5 V
Input Voltage (Min)	0.9 V
Output Voltage (Max)	5.5 V
Output Voltage (Min)	1.8 V
Output Current (Max)	0.15 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	0.9 V
Input Voltage	0.9V ~ 5.5V
	expand all
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15

Product Description

DESCRIPTION
The TPS6107x devices provide a power supply solution for products powered by either a one-cell, two-cell, or three-cell alkaline, NiCd or NiMH, or one-cell Li-ion or Li-polymer battery. Output currents can go as high as 75 mA while using a single-cell alkaline, and discharge it down to 0.9 V. It can also be used for generating 5 V at 200 mA from a 3.3 V rail or a Li-ion battery. The boost converter is based on a fixed frequency, pulse-width-modulation (PWM) controller using a synchronous rectifier to obtain maximum efficiency.
FEATURES
• 90% Efficient Synchronous Boost Converter
– 75-mA Output Current at 3.3 V From 0.9-V Input
– 150-mA Output Current at 3.3 V From 1.8-V Input
• Device Quiescent Current: 19 µA (Typ)
• Input Voltage Range: 0.9 V to 5.5 V
• Adjustable Output Voltage Up to 5.5 V
• Power-Save Mode Version Available for Improved Efficiency at Low Output Power
• Load Disconnect During Shutdown
• Overtemperature Protection
• Small 6-Pin Thin SOT23 Package
APPLICATIONS
• All One-Cell, Two-Cell, and Three-Cell Alkaline, NiCd or NiMH or Single-Cell Li Battery-Powered Products
• Portable Audio Players
• PDAs
• Cellular Phones
• Personal Medical Products
• White LED Lighting
