TPSMB16A ,Diode - Littelfuse

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

72 points

Part No

TPSMB16A
Manufacturer

Littelfuse
ChipWorker Part#

CW20236467
Category

Diode
Package

DO-214AA-2
Description

Diode TVS Single Uni-Dir 13.6V 600W Automotive 2Pin SMB T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

1500 pcs In Stock
Estimated Price

$ 0.2

Buy TPSMB16A

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TPSMB16A Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TPSMB16A Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TPSMB16A
Manufacturer	Littelfuse
ChipWorker Part#	CW20236467
Category	Diode
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	DO-214AA-2
Operating Voltage	16 V
Breakdown Voltage	16.8 V
Power Dissipation	5 W
Clamping Voltage	22.5 V
Test Current	1 mA
Max Forward Surge Current (Ifsm)	100 A
Peak Pulse Power	600 W
Min Breakdown Voltage	15.2 V
Reverse Breakdown Voltage	15.2 V
Maximum Forward Voltage (Max)	3.5 V
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	-65℃ ~ 175℃
	expand all
Size-Length	5.59 mm
Size-Width	3.94 mm
Size-Height	2.44 mm
Operating Temperature	-65℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

Littelfuse"s TPSMB16A TVS diode is designed to protect electronic components and circuits from electrical overstress from overvoltage and electrostatic discharge. Its test current is 1 mA. Its peak pulse power dissipation is 600 W. Its maximum leakage current is 1 μA. This device"s maximum clamping voltage is 22.5 V and minimum breakdown voltage is 15.2 V. This TVS diode has an operating temperature range of -55 °C to 150 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery.
