TS331ILT - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TS331ILT
Manufacturer

ST Microelectronics
ChipWorker Part#

CW2073265
Category

Comparator, Analog Comparator IC
Package

SOT-23-5
Description

STMICROELECTRONICS TS331ILT Analogue Comparator, Micropower, 1, 210ns, 1.6V to 5V, SOT-23, 5Pins
Documentation

Datasheet

TS331ILT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TS331ILT Specifications

Attribute	Attribute Value

Part Number	TS331ILT
Manufacturer	ST Microelectronics
ChipWorker Part#	CW2073265
Category	Comparator, Analog Comparator IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	5 Pin
Case/Package	SOT-23-5
Output Current	93mA @5V
Supply Current	0.034 mA
Number of Positions	5 Position
Common Mode Rejection Ratio	79 dB
Input Offset Voltage	5 mV
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	1.6V ~ 5V
	expand all
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The TS331, TS332 and TS334 are single, dual and quad micropower and low-voltage comparators. They can operate with a supply voltage ranging from 1.6 V to 5 V with a typical current consumption as low as 20 μA. In addition, rail-to-rail inputs make them a perfect choice for low-voltage applications.
Their availability in tiny packages is a real advantage for overcoming space constraints.
The TS33x are specified for temperatures between -40 °C to +125 °C, making them ideal for a wide range of applications.
**Key Features**
Supply operation from 1.6 V to 5 V
Low current consumption: 20 μA
Rail-to-rail inputs
Wide temperature range: -40 °C to +125 °C
Low output saturation voltage
Low propagation delay: 210 ns
Open-drain output
ESD tolerance: 2 kV HBM/200 V MM
SMD packages
Automotive qualified
