TSC103IPT ,Amplifier, Buffer IC - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

91 points

Part No

TSC103IPT
Manufacturer

ST Microelectronics
ChipWorker Part#

CW4851619
Category

Amplifier, Buffer IC
Package

TSSOP-8
Description

STMICROELECTRONICS TSC103IPT Current Sense Amplifier, 1 Amplifier, 15µA, TSSOP, 8Pins, -40℃, 125℃
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 1.43

Buy TSC103IPT

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TSC103IPT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TSC103IPT Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TSC103IPT
Manufacturer	ST Microelectronics
ChipWorker Part#	CW4851619
Category	Amplifier, Buffer IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	TSSOP-8
Supply Voltage (DC)	2.70V (min)
Output Current	26 mA
Supply Current	200 µA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	105 dB
Bandwidth	700 kHz
Slew Rate	600 mV/μs
Gain Bandwidth Product	0.7 MHz
Input Offset Voltage	500 µV
Input Bias Current	10 µA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	700 kHz
Minimum CMRR Range	90 dB
Supply Voltage	2.7V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
	expand all
Size-Length	4.5 mm
Size-Width	3.1 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The TSC103 measures a small differential voltage on a high-side shunt resistor and translates it into a ground-referenced output voltage. The gain is adjustable to four different values from 20 V/V up to 100 V/V by two selection pins.
Wide input common-mode voltage range, low quiescent current, and tiny TSSOP8 packaging enable use in a wide variety of applications.
The input common-mode and power-supply voltages are independent. The common-mode voltage can range from 2.9 V to 70 V in the single-supply configuration or be offset by an adjustable voltage supplied on the Vcc- pin in the dual-supply configuration.
With a current consumption lower than 360 μA and a virtually null input leakage current in standby mode, the power consumption in the applications is minimized.
**Key Features**
Independent supply and input common-mode voltages
Wide common-mode operating range: 2.9 V to 70 V in single-supply configuration,-2.1 V to 65 V in dual-supply configuration
Wide common-mode surviving range: -16 V to 75 V (reversed battery and load-dump conditions)
Supply voltage range: 2.7 to 5.5 V in single-supply configuration
Low current consumption: ICC max = 360 μA
Pin selectable gain: 20 V/V, 25 V/V, 50 V/V or 100 V/V
Buffered output
