TUSB3410 - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TUSB3410
Manufacturer

TI
ChipWorker Part#

CW270067329
Package

LQFP-32
Description

UART/I2C/IrDA Serial Port to USB Bridge
Documentation

Datasheet

TUSB3410 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TUSB3410 Specifications

Attribute	Attribute Value

Part Number	TUSB3410
Manufacturer	TI
ChipWorker Part#	CW270067329
Documentation	Datasheet
Case/Package	LQFP-32
	expand all
Product Lifecycle Status
RoHS	Non-Compliant
Lead-Free Status	Lead Free

Product Description

The TUSB3410 device provides bridging between a USB port and an enhanced UART serial port. The device contains an 8052 microcontroller unit (MCU) with 16KB of RAM that can be loaded from the host or from the external onboard memory through an I2C. The device also contains 10KB of ROM that allows the MCU to configure the USB port at boot time. The ROM code also contains an I2C bootloader. All device functions (such as the USB command decoding, UART setup, and error reporting) are managed by the internal MCU firmware in unison with the PC host.
Fully Compliant With USB 2.0 Full-Speed
Specifications: TID#40340262
Supports 12-Mbps USB Data Rate (Full Speed)
Supports USB Suspend, Resume, and Remote
Wake-Up Operations
Configurable to Bus-Powered and Self-Powered
Operation
Supports a Total of Three Input and Three Output
(Interrupt, Bulk) Endpoints
Integrated 8052 Microcontroller With:
256 × 8 RAM for Internal Data
10K × 8 ROM (With USB and I2C Bootloader)
16K × 8 RAM for Code Space Loadable From
Host or I2C Port
2K × 8 Shared RAM Used for Data
Buffers and Endpoint Descriptor Blocks (EDBs)
Master I2C Controller for EEPROM Device
Access
MCU Operates at 24 MHz, Providing 2-MIPS
Operation
128-ms Watchdog Timer
Enhanced UART Features:
Software and Hardware Flow Control
Automatic RS-485 Bus Transceiver Control,
With and Without Echo
Selectable IrDA Mode for Up to 115.2-kbps
Transfer
Software-Selectable Baud Rate From 50 BPS to
921.6 kbps
Programmable Serial-Interface Characteristics ul>
5-, 6-, 7-, or 8-Bit Characters
Even, Odd, or No Parity-bit Generation and
Detection
1-, 1.5-, or 2-Stop Bit Generation
Line Break Generation and Detection
Internal Test and Loopback Capabilities
Modem Control Functions (CTS, RTS, DSR, RI
and DCD)
Internal Diagnostic Capability
Loopback Control for Communications
Link-Fault Isolation
Break, Parity, Overrun, Framing-Error
Simulation

expand all
