USB0002DP - AVX

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

USB0002DP
Manufacturer

AVX
ChipWorker Part#

CW47120596
Category

Varistor
Package

1012
Description

Var MLV 14VAC/18VDC 4A 70V 0405 SMD T/R
Documentation

Datasheet

USB0002DP Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

USB0002DP Specifications

Attribute	Attribute Value

Part Number	USB0002DP
Manufacturer	AVX
ChipWorker Part#	CW47120596
Category	Varistor
Documentation	Datasheet
Mounting Style	Surface Mount
Case/Package	1012
Voltage Rating (DC)	18.0 V
Voltage Rating (AC)	14.0 V
Capacitance	10 pF
Number of Circuits	2 Circuit
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Voltage Rating (DC Max)	18 V
Voltage Rating (AC Max)	14 V
	expand all
Size-Length	1 mm
Size-Width	1.37 mm
Size-Height	0.66 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

Have complete control of resistance in a voltage applied circuit by using this USB0002DP MOV developed by AVX. Its maximum surge current is 4 A. This part has a pitch of 0.64 mm. This voltage dependent resistor has an operating temperature of -55 to 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. Mount your voltage dependent resistor on a printed circuit board using surface mount technology to produce the most effective results. This varistor has a voltage of 70 V. This device utilizes multilayer technology. Its capacitance value is 10pF. This product is 1 mm long, 0.66 mm tall and 1.37 mm deep. The maximum AC voltage rating is 14 VAC and the maximum DC voltage rating is 18 VDC.
