Part No

ZEN056V230A16LS
Manufacturer

TE Connectivity
ChipWorker Part#

CW53599107
Category

Zener Diode, Zener
Package

SMD-3
Description

POLYZEN Zener diode ZEN056V230A16LS Enclosure type (semiconductors) SMD TE Connectivity Zener voltage 5.6V Max. power (
Documentation

Datasheet

ZEN056V230A16LS Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	-	6 - 8 {{delivery_date}}

ZEN056V230A16LS Specifications

Attribute	Attribute Value

Part Number	ZEN056V230A16LS
Manufacturer	TE Connectivity
ChipWorker Part#	CW53599107
Category	Zener Diode, Zener
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SMD-3
Operating Voltage	5.6 V
Capacitance	4200 pF
Breakdown Voltage	16 V
Number of Circuits	1 Circuit
Number of Positions	3 Position
Power Dissipation	700 mW
Holding Current	2.3 A
Clamping Voltage	5.6 V
Test Current	100 mA
Max Breakdown Voltage	5.75 V
Zener Voltage	5.6 V
Peak Pulse Power	0.7 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	0.7 W
Voltage Rating	16 V
	expand all
Size-Length	4.15 mm
Size-Width	4.15 mm
Size-Height	2 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ELV Compliant	Compliant

Product Description

ESD Suppressor Polymer 15KV 3-Pin SMD T/R
