242126 - Amphenol

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

242126
Manufacturer

Amphenol
ChipWorker Part#

CW34822163
Category

RF Coaxial Cable Assembly, RF Connector Accessory
Package

SMA
Description

Conn SMA-MCX Adapter PL/RCP 0Hz to 6GHz 50Ω ST Gold
Documentation

Datasheet

242126 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

242126 Specifications

Attribute	Attribute Value

Part Number	242126
Manufacturer	Amphenol
ChipWorker Part#	CW34822163
Category	RF Coaxial Cable Assembly, RF Connector Accessory
Documentation	Datasheet
Mounting Style	Surface Mount
Case/Package	SMA
Number of Contacts	1 Contact
Contact Plating	Gold
Mounting Angle	180 °
Operating Temperature (Max)	165 ℃
Operating Temperature (Min)	-65 ℃
	expand all
Size-Length	22.96 mm
Contact Material	Beryllium Copper
Operating Temperature	-65℃ ~ 165℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

The 242126 is a MCX Jack to SMA Plug Straight Adapter with gold-plated beryllium copper contacts and gold-plated brass body. It features PTFE insulation and 6GHz maximum frequency. This adapter is commonly used in applications requiring 2 dissimilar RF interfaces to be connected.
50R Impedance
-65 to 165°C Temperature range

expand all
