2761606 - Phoenix

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

2761606
Manufacturer

Phoenix
ChipWorker Part#

CW57724207
Category

D-Sub Connector, D-Sub Standard Connector, Connector D-Subminiature
Description

Male D-Sub Bus Connector 100 Milli-Amp, 50V, Metal Plated ABS Housing, 15Positions,
Documentation

Datasheet

2761606 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

2761606 Specifications

Attribute	Attribute Value

Part Number	2761606
Manufacturer	Phoenix
ChipWorker Part#	CW57724207
Category	D-Sub Connector, D-Sub Standard Connector, Connector D-Subminiature
Documentation	Datasheet
Mounting Style	Screw
Number of Contacts	15 Contact
Gender	Male
Current Rating	1 A
Number of Rows	2 Row
Number of Positions	15 Position
Number of Mating Cycles	50 Cycle
Current Rating (Max)	0.1 A
Operating Temperature (Max)	75 ℃
Operating Temperature (Min)	-20 ℃
Voltage Rating (Max)	50 V
Voltage Rating	60 V
	expand all
Size-Length	64.7 mm
Size-Width	16 mm
Size-Height	64.7 mm
Contact Material	Copper Alloy
Material	Acrylonitrile Butadiene Styrene (ABS)
Operating Temperature	-20℃ ~ 75℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
HTS Code	8536694030
ECCN Code	EAR99

Product Description

PHOENIX CONTACT"s SUBCON product provides a means to make D-SUB cable assemblies without the hassle of soldering or crimping. The SUBCON product provides connection from the pins of a D-SUB connector to individual screw actuated terminal blocks all in a D-SUB clamshell housing. This means that the only tool required to configure a cable is a screwdriver.
**Features:**
* Metallized Housing
* Integral Jack Screws
* Integral Strain Relief
* D-SUB to MKDSC 1.5 Terminal Blocks
* 9/25 Pin Male or Female Versions
* Max. Cable Diameter: 10 mm; AWG 26-14
**Benefits:**
* EMI/RFI Shielded (Ideal for Sensitive Communication Signals)
* Secure Connection of Cable Assembly to Mating Receptacle
* Secure Connection of SUBCON to Cable
* Easy Means to Construct Cable Assemblies; No More Soldering or Crimping; Wide Range of Product to Suit Common Applications
