AD5066BRUZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD5066BRUZ
Manufacturer

ADI
ChipWorker Part#

CW1750327
Category

Digital to Analog, DAC IC
Package

TSSOP-16
Description

ANALOG DEVICES AD5066BRUZ Digital to Analog Converter, 16Bit, Serial, 2.7V to 5.5V, TSSOP, 16Pins
Documentation

Datasheet

AD5066BRUZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD5066BRUZ Specifications

Attribute	Attribute Value

Part Number	AD5066BRUZ
Manufacturer	ADI
ChipWorker Part#	CW1750327
Category	Digital to Analog, DAC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	TSSOP-16
Number of Outputs	4 Output
Supply Current	2.5 mA
Number of Channels	4 Channel
Number of Positions	16 Position
Number of Bits	16 Bit
Power Dissipation	0.0125 W
Resolution (Bits)	16.0 Bit
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	12.5 mW
Number of DACs	4 DAC
Supply Voltage	2.7V ~ 5.5V
	expand all
Size-Length	5.1 mm
Size-Width	4.5 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The AD5066BRUZ is a low power 16-bit quad-channel un-buffered voltage output Digital-to-analog Converter offering relative accuracy specifications of ±1LSB INL with individual reference pins and can operate from a single 2.7 to 5.5V supply. The part uses a versatile 3-wire, low power Schmitt trigger serial interface that operates at clock rates up to 50MHz and is compatible with standard SPI®, QSPI™, MICROWIRE™ and most DSP interface standards. The AD5066 incorporates a power-on reset circuit that ensures the DAC output powers up to zero scale or midscale and remains there until a valid write to the device takes place. The AD5066 contains a power-down feature that reduces the current consumption of the device to typically 400nA at 5V and provides software selectable output loads while in power-down mode. The outputs of DAC can be updated simultaneously using the hardware LDAC function with the added functionality of user software selectable DAC channels to update simultaneo
Low total unadjusted error of ±0.1mV typically
Low zero code error of 0.05mV typically
Individually buffered reference pins
Power-on reset to zero scale or midscale
Per channel power-down with 3 power-down functions
Hardware LDAC with software LDAC override function
CLR function to programmable code
