AD5328ARUZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD5328ARUZ
Manufacturer

ADI
ChipWorker Part#

CW402596
Category

Digital to Analog, DAC IC
Package

TSSOP-16
Description

ANALOG DEVICES AD5328ARUZ Digital to Analog Converter, 12Bit, 167KSPS, Serial, 2.5V to 5.5V, TSSOP, 16Pins
Documentation

Datasheet

AD5328ARUZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD5328ARUZ Specifications

Attribute	Attribute Value

Part Number	AD5328ARUZ
Manufacturer	ADI
ChipWorker Part#	CW402596
Category	Digital to Analog, DAC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	TSSOP-16
Number of Outputs	8 Output
Supply Current	1 mA
Number of Channels	8 Channel
Number of Positions	16 Position
Number of Bits	12 Bit
Power Dissipation	0.0045 W
Sample Rate	167 kHz
Resolution (Bits)	12.0 Bit
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	4.5 mW
Number of DACs	8 DAC
Supply Voltage	2.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.5 V
	expand all
Size-Length	5 mm
Size-Width	4.4 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The AD5328ARUZ is a 2.5 to 5.5V Octal Voltage Output 12-bit DAC that operate from a single 2.5 to 5.5V supply, consuming 0.7mA typical at 3V. The on-chip output amplifiers allow the outputs to swing rail-to-rail with a slew rate of 0.7V/µs. It uses a versatile 3-wire serial interface that operates at clock rates up to 30MHz and is compatible with standard SPI, QSPI, MICROWIRE and DSP interface standards. The references for the eight DACs are derived from two reference pins (one per DAC quad). These reference inputs can be configured as buffered, unbuffered or VDD inputs. The parts incorporate a power-on reset circuit, which ensures that the DAC outputs power up to 0V and remain there until a valid write to the device takes place. The outputs of all DACs may be updated simultaneously using the asynchronous LDAC input. The parts contain a power-down feature that reduces the current consumption of the devices to 400nA at 5V (120nA at 3V).
Low power operation
Guaranteed monotonic by design over all codes
Double-buffered input logic
Power-on reset to 0V
On-chip rail-to-rail output buffer amplifiers
Individual channel power-down programmability
Simultaneous update of outputs (LDAC)
