Part No

AD5360
Manufacturer

ADI
ChipWorker Part#

CW353136296
RoHS

Lead free / RoHS Compliant
Description

16Channel, 16Bit, Serial Input, Voltage-Output DAC
Documentation

Datasheet

AD5360 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD5360 Specifications

Attribute	Attribute Value

Part Number	AD5360
Manufacturer	ADI
ChipWorker Part#	CW353136296
Documentation	Datasheet
	expand all
Product Lifecycle Status	Active
RoHS	RoHS Compliant

Product Description

GENERAL DESCRIPTION
The AD5360/AD5361 contains 16, 16/14-bit DACs in a single, 56-lead, LFCSP or 52-lead LQFP package. It provides buffered voltage outputs with a span 4 times the reference voltage. The gain and offset of each DAC can be independently trimmed to remove errors. For even greater flexibility, the device is divided into two groups of 8 DACs, and the output range of each group can be independently adjusted by an offset DAC.
FEATURES
16-channel DAC in 52-LQFP and 56-LFCSP
Guaranteed monotonic to 16/14 bits
Nominal output voltage range of -10 V to +10 V
Multiple output spans available
Temperature Monitoring Function
Channel Monitoring Multiplexer
GPIO Function
System calibration function allowing user-programmable offset and gain
Channel grouping and addressing features
Data error checking feature
SPI compatible serial interface
2.5 V to 5.5 V digital interface
Power-on reset
Digital reset (RESET)
Clear function to user-defined SIGGND (CLRpin)
Simultaneous update of DAC outputs (LDACpin)
APPLICATIONS
Instrumentation
Industrial control systems
Level setting in automatic test equipment (ATE)
Variable optical attenuators (VOA)
Optical Line Cards
