ADV7125JSTZ240 ,Digital to Analog, DAC IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

191 points

Part No

ADV7125JSTZ240
Manufacturer

ADI
ChipWorker Part#

CW1814230
Category

Digital to Analog, DAC IC
Package

LQFP-48
Description

ANALOG DEVICES ADV7125JSTZ240 Digital to Analog Converter, 8Bit, 240MSPS, Parallel, 3V to 3.6V, 4.75V to 5.25V, LQFP, 48Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

8 pcs In Stock
Estimated Price

$ 5.1

Buy ADV7125JSTZ240

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADV7125JSTZ240 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADV7125JSTZ240 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADV7125JSTZ240
Manufacturer	ADI
ChipWorker Part#	CW1814230
Category	Digital to Analog, DAC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	48 Pin
Case/Package	LQFP-48
Number of Outputs	3 Output
Supply Current	67 mA
Number of Channels	3 Channel
Number of Positions	48 Position
Number of Bits	8 Bit
Power Dissipation	485 mW
Sample Rate	240 Msps
Power Consumption	30 mW
Resolution (Bits)	8.0 Bit
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	30 mW
Number of DACs	3 DAC
Supply Voltage	3.3V ~ 5V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	7 mm
Size-Width	7 mm
Size-Height	1.4 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

Product Details
The ADV7125 (ADV®) is a triple high speed, digital-to-analog converter (DAC) on a single monolithic chip. It consists of three high speed, 8-bit video DACs with complementary outputs, a standard TTL input interface, and a high impedance, analog output current source.
The ADV7125 has three separate 8-bit-wide input ports. A single +5 V/+3.3 V power supply and clock are all that are required to make the device functional. The ADV7125 has additional video control signals, composite SYNC and BLANK as well as a power save mode.
The ADV7125 is fabricated in a 5 V CMOS process. Its monolithic CMOS construction ensures greater functionality with lower power dissipation. The ADV7125 is available in 48- lead LQFP and 48-lead LFCSP packages.
Product Highlights
1. 330 MSPS (3.3 V only) throughput.
2. Guaranteed monotonic to eight bits.
3. Compatible with a wide variety of high resolution color graphics systems, including RS-343A and RS-170.
Applications
Digital video systems
High resolution color graphics
Digital radio modulation
Image processing
Instrumentation
Video signal reconstruction
Automotive infotainment units
### Features and Benefits
330 MSPS throughput rate
Triple 8-bit DACs
RS-343A-/RS-170-compatible output
Complementary outputs
DAC output current range: 2.0 mA to 26.5 mA
TTL-compatible inputs
Internal reference (1.235 V)
Single-supply +5 V/+3.3 V operation
48-lead LQFP and LFCSP
Low power dissipation (30 mW minimum at 3 V)
Low power standby mode (6 mW typical at 3 V)
Industrial temperature range (−40°C to +85°C)
RoHS compliant packages
Qualified for automotive applications
