AD5522JSVUZ ,Digital to Analog, DAC IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

153 points

Part No

AD5522JSVUZ
Manufacturer

ADI
ChipWorker Part#

CW10223734
Category

Digital to Analog, DAC IC
Package

TQFP-80
Description

ANALOG DEVICES AD5522JSVUZ Special Function IC, Quad Parametric Measurement Unit, Integrated 16Bit DAC, 10V to 28V, HTQFP-80
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 73.48

Buy AD5522JSVUZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AD5522JSVUZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AD5522JSVUZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD5522JSVUZ
Manufacturer	ADI
ChipWorker Part#	CW10223734
Category	Digital to Analog, DAC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	80 Pin
Case/Package	TQFP-80
Supply Voltage (DC)	10.0V (min)
Number of Positions	80 Position
Power Dissipation	800 mW
Operating Temperature (Max)	90 ℃
Operating Temperature (Min)	25 ℃
Supply Voltage (Max)	28 V
Supply Voltage (Min)	10 V
	expand all
Size-Length	12.2 mm
Size-Width	12.2 mm
Size-Height	1.2 mm
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

Product Details
The AD5522 is a high performance, highly integrated parametric measurement unit consisting of four independent channels. Each per-pin parametric measurement unit (PPMU) channel includes five 16-bit, voltage output DACs that set the programmable input levels for the force voltage inputs, clamp inputs, and comparator inputs (high and low). Five programmable force and measure current ranges are available, ranging from ±5 μA to ±80 mA. Four of these ranges use on-chip sense resistors; one high current range up to ±80 mA is available per channel using off-chip sense resistors. Currents in excess of ±80 mA require an external ampli-fier. Low capacitance DUT connections (FOH and EXTFOH) ensure that the device is suited to relayless test systems.
The PMU functions are controlled via a simple 3-wire serial interface compatible with SPI, QSPI™, MICROWIRE™, and DSP interface standards. Interface clocks of 50 MHz allow fast updating of modes. The low voltage differential signaling (LVDS) interface protocol at 83 MHz is also supported. Comparator outputs are provided per channel for device go-no-go testing and character-ization. Control registers allow the user to easily change force or measure conditions, DAC levels, and selected current ranges. The SDO (serial data output) pin allows the user to read back information for diagnostic purposes.
**Applications**
* Automatic Test Equipment (ATE)
per pin Parametric Measurement Unit
Continuity & Leakage Testing
Device Power Supply
* Instrumentation
SMU (Source Measure Unit)
Precision Measurement
### Features and Benefits
Quad parametric measurement unit (PMU)
FV, FI, FN (high-Z), MV, MI functions
4 Programmable Current Ranges (Internal RSENSE)
±5uA, ±20uA, ±200uA and ±2mA
1 Programmable Current Range up to ±80mA (external RSENSE)
22.5 V FV Range with Asymmetrical Operation
Integrated 16-Bit DACs Provide Programmable Levels
Gain and offset correction on chip
Low capacitance outputs suited to relay less systems
On-chip comparators per channel
See Data Sheet for Additional Information
